PSF-TEF1-COOH-3C-FLAG®-6HIS - C-TERMINAL 6 HIS AND FLAG® DUAL TAG YEAST PLASMID OGS1977-5UG

NACRES:

NA.85

This plasmid is designed to express tagged proteins in yeast cells (Saccharomyces cerevisiae). The plasmid contains an auxotrophic Uracil selection expression cassette (URA3) that allows for the positive selection of yeast that are deficient in the URA3 gene (YEL021W). This is typically achieved by growing the yeast in minimal media that is reconstituted with the essential amino acids and nucleotides but excluding Uracil.
About the Peptide Tag:This plasmid contains a c-terminal FLAG epitope tag that can be fused to a gene of interest to allow protein detection and/or purification. The sequence of the tag is: DYKDDDDK. This plasmid also contains a secondary Hexa-Histidine (6His) tag protein tag. The sequence of this tag is: HHHHHHWe provide a range of dual peptide tag plasmids. This is because some peptide tags provide specific biological properties (e. g., small molecule affinity new epitopes solubility or protein secretion) that are not provided by others.
About the Cleavage Tag: This plasmid also encodes a protease cleavage site that is designed to be positioned between your gene of interest and the tag to allow the removal of the tag following protein purification or isolation. This plasmid contains a 3C cleavage tag. The protein sequence of the cleavage tag is: LEVLFQGP. Human Rhinovirus (HRV) 3C Protease is a highly specific protease that cleaves between the Glu and Gly residues of its recognition site. It is often produced with the trademname PreScission protease.
Promoter Expression Level: This plasmid contains the Yeast Elongation Factor Alpha promoter (TEF1). This is the strongest of the yeast promoters that we sell. It is a constitutive promoter and requires no induction. If you are interested in weaker promoters levels than we also stock plasmids that contain the following promoters in order of decreasing strength TPI (strong), ADHI (medium), STE5 (weak). We also stock Galactose inducible promoter plasmids if inducible expression is required. Please contact us for further information.
Sequence
Quick-reference Plasmid Map,
Please select the file type you require. For reference most cloning programs will import a .gb (Genbank) file and will show all of the plasmids features automatically when downloaded and imported.
Genebank Vector Sequence File,
FASTA Vector Sequence File,
Full Plasmid Map,
Analysis Note
Looking for more vector options to move your experiments forward faster? Consider a custom cloning vector designed and built by Oxford Genetics™. Find out more at Oxford Genetics, - Sigma's partner for cloning and expression vectors for molecular biology and synthetic biology applications.
FLAG is a registered trademark of Sigma-Aldrich Co. LLC
Oxford Genetics is a trademark of Oxford Genetics Ltd

form	buffered aqueous solution
mol wt	size 6783 bp
conjugate	6-His tagged, FLAG® tagged
Origin of replication	2Micron, pUC (500 copies)
Peptide cleavage	3C
Peptide tag location	C-terminal
Promoter	Promoter name: TEF1 Promoter activity: constitutive Promoter type: yeast
bacteria selection	kanamycin
reporter gene	none
shipped in	ambient
storage temp.	20°C
yeast selection	uracil

RIDADR	NONH for all modes of transport
Flash Point F	Not applicable
Flash Point C	Not applicable
