- Производитель:
- Milli-Q
eCl@ss: | 33050190 |
NACRES: | JA.14 |
Features and Benefits
- Millipak® membrane filters are made with Durapore® PVDF membranes to provide high flow rates and throughputs, low extractable and broad chemical compatibility.
- Gamma-irradiated for additional bacteria control.
- The membrane is supported by a rigid plastic disc with channels that ensures high water flow and resistance to pressure variations without the risk of membrane rupture.
- Millipak® membrane filters use the unique, clean stacked disc design, allowing minimal hold-up volume and particle shedding.
- Connects to the outlet of the water delivery point, such as the PODs of Milli-Q® water purification systems.The protective bell protects against intrusion of airborne bacteria contamination during dispensing.
- The protective bell protects against intrusion of airborne bacteria contamination during dispensing.
- Care-free maintenance: the filter is easily fitted and replaced.
- Device configuration: Gamma Gold Capsule.
- Sterile unit.
- Delivered hermetically sealed, with its Certificate of Quality.
Directions for Use
- Organism Retention: Microorganisms
- Mode of Action: Filtering
- Application: General laboratory analysis
- Intended Use: Water purification
- Instructions for Use: This item provides water filtered through 0.22 µm sterilizing-grade membranes, and is considered to be a pesticide device under FIFRA . Refer to system equipment user guide section "Using the System" (available on USB key in the system box)
- Storage Statement: Store in dry location
- Disposal Statement: Dispose of in accordance with applicable federal, state and local regulations.
Preparation Note
This product was manufactured with a Durapore® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Analysis Note
Bacterial Retention
Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10 CFU/cm using ASTM® F838 methodology.
Gravimetric Extractables: using sterilized device after a 200 mL flush and 24 hours in water at controlled room temperature
Durapore is a registered trademark of Merck KGaA, Darmstadt, Germany
Emprove is a registered trademark of Merck KGaA, Darmstadt, Germany
MILLI-DI is a registered trademark of Merck KGaA, Darmstadt, Germany
MILLIPAK is a registered trademark of Merck KGaA, Darmstadt, Germany
Milli-Q is a registered trademark of Merck KGaA, Darmstadt, Germany
Quality Level | 400, |
material | PVDF membrane |
sterility | sterile |
product line | EMPROVE® Filter |
feature | hydrophilic |
Торговая марка | Millipak® |
parameter | 0.35 bar max. differential pressure at 123 °C (Forward), 0.7 bar max. differential pressure at 25 °C (Reverse), 1.7 bar max. differential pressure at 80 °C (Forward), 4.1 bar max. differential pressure at 25 °C (Forward), 5.2 bar max. inlet pressure at 25 °C |
inlet connection diam. | 1/4 in. |
outlet connection diam. | 1/4 in. |
impurities | <0.5 EU/mL USP bacterial endotoxins (LAL test, sample aqueous extraction) |
gravimetric extractables | 1.5 mg/device |
matrix | Durapore® |
pore size | 0.22 µm pore size |
fitting | male NPT inlet connection, outlet stepped hose barb (with bell) |
compatibility | for use with Alpha-Q, for use with Milli-DI®, for use with Milli-Q® Academic, for use with Milli-Q® Biocel, for use with Milli-Q® Direct, for use with Milli-Q® Element, for use with Milli-Q® Gradient, for use with Milli-Q® Plus, for use with Milli-Q® Reference, for use with Milli-Q® Synthesis |
shipped in | ambient |
